US Optics SVS 1-6X24 Optic No Mount

$1,239.99

New US Optics SVS 1-6 optic without mount. The SVS 1-6x optic is a true 1x optic with a 34mm tube, second focal plane 2MOA daylight visible red dot, MIL scale reticle, built in throw lever, and capped zeroing knobs for both windage and elevation with 2/10 MIL adjustments. The second focal plane red dot intensity can be adjusted via a 10-position rheostat, with the lower 3 settings being night vision compatible. The MIL Scale reticle features a set of simple crosshairs with 2 full MILs left and right, as well as 1, 2, 4, and 6 MILS below the center on the vertical axis.

SVS 1-6x Specifications
• Elevation Knob: 2/10 MIL Zeroing Knobs
• Windage Knob: 2/10 MIL Zeroing Knobs
• Reticle: SVS MIL Scale, Second Focal Plane
• Red Dot: 2 MOA, Second Focal Plane

Common Characteristics
• Magnification: 1-6x
• Diopter: +2 to -3
• Parallax Adjustment: Fixed @ 100yds
• Field of View @ 1x: 107.5' @ 100yds.
• Field of View @ 6x: 18.65 ’ @ 100 yards
• Eye Relief: 3.5”
• Objective Lens Housing Diameter: 1.338? / 34mm
• Tube Diameter: 1.33” / 34mm
• Overall Length: 10.130 ”
• Objective Lens Diameter: 0.94” / 24mm
• Ocular Lens Diameter: 1.45” / 37mm
• Weight: 22.2oz
• Illumination: 2 MOA Red Dot
• Battery: Lithium Coin, CR2032
• Battery Runtime: Up to 500 Hours
• Material: Aluminum, 6061-T6
• Finish Color: Matte Black
